Double Mast Aluminum AWP
PRODUCT DETAILS
| Model | AMWP7.5-2100 | AMWP9-2100 |
| Max. Working Height | 9.50m | 11.00m |
| Max. Platform Height | 7.50m | 9.00m |
| Loading Capacity | 200kg | 150kg |
| Occupants | 1 | 1 |
| Overall Length | 1.46m | 1.46m |
| Overall Width | 1.01m | 1.01m |
| Overall Height | 1.99m | 1.99m |
| Platform Dimension | 1.00m×0.65m | 1.00m×0.65m |
| Wheel Base | 1.14m | 1.14m |
| Turning Radius | 0 | 0 |
| Travel Speed(Stowed) | 4km/h | 4km/h |
| Travel Speed(Raised) | 1.1km/h | 1.1km/h |
| Up/Down Speed | 48/40sec | 56/49sec |
| Gradeability | 25% | 25% |
| Drive Tyres | Φ305×100mm | Φ305×100mm |
| Drive Motors | 2×24VDC/0.5kW | 2×24VDC/0.5kW |
| Lifting Motor | 24VDC/1.3kW | 24VDC/1.3kW |
| Battery | 2×12V/100Ah | 2×12V/100Ah |
| Charger | 24V/15A | 24V/15A |
| Weight | 1270kg | 1345kg |
1. Battery power, no need for external power supply, convenient and fast to use;
2. Single handle operation, proportional control, full-stroke walking;
3. Non-marking rubber tires can effectively protect the ground;
4. The whole machine has a compact structure, small and flexible, and convenient to enter a small space;
5. The driving wheel has an automatic braking function;
6. The guide wheel holding mechanism is adopted between each mast. The uniquely designed guide wheel holding technology not only minimizes the dynamic gap between adjacent masts, but also reduces the friction between the guide wheel and the mast;
7. Both the platform and the ground can be controlled up and down, with up and down control switch;
8. The chassis is equipped with standard forklift holes, which is convenient and safe for equipment loading and unloading;
9. The control voltage is DC 24V to ensure the safety of operators;
10. The electrical control system is equipped with double contactors to maximize the safety of operation;
11. Both the platform and the ground are equipped with an emergency stop button, which can quickly cut off the power in an emergency;
12. The charger has an intelligent protection function to prevent overcharging, and has a reminder function during charging;
13. The system is equipped with an emergency lowering valve. When the system is working, due to a sudden power failure, the lifting equipment can be safely lowered, and the operating mechanism is external, which is convenient to operate;
14. Equipped with pipeline explosion-proof system;
15. The platform is equipped with safety belt hooks to ensure safe operation;
16. Equipped with electric limit and built-in limit of oil cylinder, limit protection is safer;
17. With tilt protection function;
18. With fault diagnosis function;
19. With charging protection function;
20. Equipped with standard forklift holes;
21. Equipped with buzzer, horn and strobe light;
22. The surface treatment of steel structure adopts electrostatic spray paint after shot blasting, and the coating is firm and beautiful;
23. The threshold slope is randomly equipped, suitable for the threshold height: not less than 50mm.
